What is PM-OLED?  (Graphic OLED Display)
PM-OLED stands for Passive Matrix OLED (or, in full, Passive Matrix Organic Light Emitting Diodes). Passive Matrix refers to the arrangement of the driving electrodes in the OLED display.
If an OLED display is compared to an LCD display, PM-OLED is more like STN LCD, whereas
AM-OLED is like TFT LCD. PM-OLED displays are not suitable for displaying dynamic images as the reaction speed is relatively slow and it is difficult to develop large-size panels, but their power consumption is relatively low. AM-OLED displays, by contrast, have a fast reaction speed and can come in a variety of sizes – including larger displays – but they involve higher power consumption.
graphic_display
The structure of PM-OLED displays is relatively simple, with the driving current method determining the grayscale, resolution, and picture quality performance. Most PM-OLED displays are monochrome (Graphic Display) or multi-color products. The nature of the drive method means that the resolution of PM-OLED displays cannot be improved, meaning their use is limited to small-scale devices with a maximum size of about 5 inches.
PM-OLED does, however, have a number of advantages. For starters, they are cheaper and have very
low power consumption. The nature of the displays also mean they can display pure black and can offer no glare (meaning they are readable in direct sunlight) and high brightness. They are also easy to drive as most PM-OLEDs have  I2C, SPI interface.
The PM-OLED displays that Panox Display supplies can be used in 4G-LTE, handheld, kid watches, instruments, car displays, smart homes, and electronic cigarettes.

Filters

Configure Your Item Here
  • Size(inch)
    • 0.39~1.0
    • 1.0~1.9
    • 2.0~2.9
    • 3.0~3.9
    • 4.0~4.9
    • 5.0~5.9
    • 6.0~6.9
    • 7.0~7.9
    • 8.0~9.9
    • 10~20
  • Interface
    • I2C
    • SPI
    • Parallal
    • MCU
    • CPU
    • RGB
    • MIPI
    • LVDS
    • eDP
    • HDMI
  • Display Color
    • Monochrome
    • Double Color
    • Full Color
  • Orientation
    • Landscape
    • Portrait

Model Size Display Type Resolution Interface Display Brand Image
0.66 inch Graphic OLED Display White On Black For E-cigarette
0.66 inch Graphic OLED Display White On Black For E-cigarette
Size0.66
Display TypePMOLED
Resolution64x48
InterfaceI2C,SPI
Display BrandVisonox/Univision
0.66 PMOLED 64x48 I2C,SPI Visonox/Univision 0.66 inch Graphic OLED Display White On Black For E-cigarette
0.69 inch  Graphic OLED Display SSD1306
0.69 inch Graphic OLED Display SSD1306
Size0.69
Display TypePMOLED
Resolution96x16
InterfaceI2C,SPI
Display BrandVisonox/Univision
0.69 PMOLED 96x16 I2C,SPI Visonox/Univision 0.69 inch  Graphic OLED Display SSD1306
0.95 inch Full Color OLED  For  Wearable
0.95 inch Full Color OLED For Wearable
Size0.95
Display TypePMOLED
Resolution96x64
InterfaceSPI,Parallal
Display BrandVisonox/Univision
0.95 PMOLED 96x64 SPI,Parallal Visonox/Univision 0.95 inch Full Color OLED  For  Wearable
0.96 inch Graphic OLED For E-cigarette
0.96 inch Graphic OLED For E-cigarette
Size0.96
Display TypePMOLED
Resolution128x64
InterfaceI2C,SPI,Parallal
Display BrandVisonox/Univision
0.96 PMOLED 128x64 I2C,SPI,Parallal Visonox/Univision 0.96 inch Graphic OLED For E-cigarette
1.3 inch P Full Color OLED Full Color For Instrument
1.3 inch P Full Color OLED Full Color For Instrument
Size1.3
Display TypePMOLED
Resolution128(RGB)×96
InterfaceSPI,Parallal
Display BrandUnivision
1.3 PMOLED 128(RGB)×96 SPI,Parallal Univision 1.3 inch P Full Color OLED Full Color For Instrument
1.3 inch Graphic OLED  White/Blue/Yellow On Black
1.3 inch Graphic OLED White/Blue/Yellow On Black
Size1.3
Display TypePMOLED
Resolution128x64
InterfaceI2C,SPI
Display BrandVisonox/Univision
1.3 PMOLED 128x64 I2C,SPI Visonox/Univision 1.3 inch Graphic OLED  White/Blue/Yellow On Black
1.54 inch Graphic OLED Display Low Consumption
1.54 inch Graphic OLED Display Low Consumption
Size1.54
Display TypePMOLED
Resolution128×64
InterfaceI2C,SPI,CPU
Display BrandVisonox/Truly
1.54 PMOLED 128×64 I2C,SPI,CPU Visonox/Truly 1.54 inch Graphic OLED Display Low Consumption
1.7 inch  PMOLED For Wearable Smartwatch
1.7 inch PMOLED For Wearable Smartwatch
Size1.8
Display TypePMOLED
Resolution128(RGB)×160
InterfaceCPU
Display BrandSamsung
1.8 PMOLED 128(RGB)×160 CPU Samsung 1.7 inch  PMOLED For Wearable Smartwatch
1.77  inch Full Color OLED Display
1.77 inch Full Color OLED Display
Size1.77
Display TypePMOLED
Resolution160(RGB)×128
InterfaceSPI,Parallal
Display BrandRitdisplay
1.77 PMOLED 160(RGB)×128 SPI,Parallal Ritdisplay 1.77  inch Full Color OLED Display
2.23 inch PMOLED SPI/I2C  For Instrument
2.23 inch PMOLED SPI/I2C For Instrument
Size2.23
Display TypePMOLED
Resolution128×32
InterfaceI2C,SPI,Parallal
Display BrandWiseChip
2.23 PMOLED 128×32 I2C,SPI,Parallal WiseChip 2.23 inch PMOLED SPI/I2C  For Instrument
2.4 inch Graphic OLED Display For Instrument
2.4 inch Graphic OLED Display For Instrument
Size2.4
Display TypePMOLED
Resolution128×64
InterfaceI2C,SPI,Parallal
Display BrandRitdisplay
2.4 PMOLED 128×64 I2C,SPI,Parallal Ritdisplay 2.4 inch Graphic OLED Display For Instrument
2.7 inch PMOLED For Instrument
2.7 inch PMOLED For Instrument
Size2.7
Display TypePMOLED
Resolution128×64
InterfaceI2C,SPI,Parallal
Display BrandRitdisplay
2.7 PMOLED 128×64 I2C,SPI,Parallal Ritdisplay 2.7 inch PMOLED For Instrument

It`s just a beginning to get display panels from us, then clients need to solve cover glass/touch panel, driving board, connectors on PCB.Fortunately Panox Display provide complete display solutions.
Connectors
Panox Display provides free connectors for clients who purchase more than five products from us. Our product range includes connectors from Molex, Kyocera, AXE, AXG, JAE, Hiros, and more.
Cover Glass/Touch Panels
Panox Display provides a customized cover glass/touch panel service. We supply cover glass from Gorilla, AGC, and Panda, which all have excellent optical performance. We also supply driver ICs from Goodix and Focaltech.
Controller/Driver Boards
If your applications are directly connected to a PC, a cellphone, or Raspberry Pi, and you have enough space to insert a board to input video, Panox Display can provide customized Controller/Driver boards with input connections for VGA, HDMI, DVI, DP, Type-C video input, MIPI, RGB, LVDS, and eDP.
The functions of our boards include, but are not limited to, adjustment of brightness, sound output, touch interface, extra data transmission, and gyroscope.
